If you need to interface with XStudio you will want to use the REST API.
Here's a simple (Java) Example to show how to authenticate, get and post data.
package com.xqual.xrest_client;
import java.io.BufferedReader;
import java.io.DataOutputStream;
import java.io.InputStreamReader;
import java.net.CookieManager;
import java.net.CookiePolicy;
import java.net.CookieStore;
import java.net.HttpCookie;
import java.net.HttpURLConnection;
import java.net.URL;
import java.util.List;
import java.util.Map;
public class CClient {
private final String USER_AGENT = "Mozilla/5.0";
public HttpURLConnection con = null;
private CookieManager cookieManager = null;
private CookieStore cookieStore = null;
private void start() throws Exception {
// used to store cookies
cookieManager = new CookieManager();
cookieManager.setCookiePolicy(CookiePolicy.ACCEPT_ALL);
cookieStore = cookieManager.getCookieStore();
// ------------------
// FIRST AUTHENTICATE
// ------------------
String serverURL = "http://192.168.100.180:8080/xqual/api";
sendPost(serverURL + "?command=authenticate&username=admin&password=password&userLanguage=en_US", "");
// Cookie: message --> local store
Map<String, List<String>> headerFields = con.getHeaderFields();
List<String> cookiesHeader = headerFields.get("Set-Cookie");
if (cookieStore != null) {
if (cookiesHeader != null) {
if (cookiesHeader.size() > 0) {
for (String cookieHeader : cookiesHeader) {
if (cookieHeader != null && cookieHeader.length() > 0) {
List<HttpCookie> cookiesList = HttpCookie.parse(cookieHeader);
if (cookiesList != null) {
if (cookiesList.size() > 0) {
for (HttpCookie cookie : cookiesList) {
if (cookie != null) {
try {
if (cookie.toString().startsWith("JSESSIONID")) { // we need to store ONLY this one !!!
System.err.println("<<< saving cookie in the local store: " + cookie.toString());
cookieStore.add(null, cookie);
}
} catch (Exception e) {
System.err.println("couldn't store cookie!");
};
}
}
} else {
System.err.println("no cookie available in the message");
}
} else {
System.err.println("null cookies list in the message!");
}
} else {
System.err.println("null or empty cookie header in the message!");
}
}
} else {
System.err.println("no cookie header in the message!");
}
} else {
System.err.println("null cookies header in the message"); // in the next connections, this is normal
}
} else {
System.err.println("null local cookie store!");
}
// --------------------------------
// THEN SEND YOUR GET/POST MESSAGES
// --------------------------------
// get the server's settings
sendGet(serverURL + "?command=getSettings");
// get the requirements tree
sendGet(serverURL + "?command=getRequirementsTree");
// create a new requirement
StringBuffer bodyContent = new StringBuffer();
bodyContent.append("{");
bodyContent.append(" \"form\": {");
bodyContent.append(" \"formItem\": [{");
bodyContent.append(" \"id\": 2,"); // name
bodyContent.append(" \"value\": \"new requirement\"");
bodyContent.append(" },");
bodyContent.append(" {");
bodyContent.append(" \"id\": 3,"); // description
bodyContent.append(" \"content\": \"CREATE requirement [b]description[/b] 2\"");
bodyContent.append(" },");
bodyContent.append(" {");
bodyContent.append(" \"id\": 5,"); // status
bodyContent.append(" \"value\": 20");
bodyContent.append(" },");
bodyContent.append(" {");
bodyContent.append(" \"id\": 4,"); // priority
bodyContent.append(" \"value\": 20");
bodyContent.append(" },");
bodyContent.append(" {");
bodyContent.append(" \"id\": 8,"); // risk
bodyContent.append(" \"parameters\": \"1;2;3;4\",");
bodyContent.append(" \"value\": 2345");
bodyContent.append(" },");
bodyContent.append(" {");
bodyContent.append(" \"id\": 6,"); // type
bodyContent.append(" \"value\": \"Functional\"");
bodyContent.append(" }]");
bodyContent.append(" }");
bodyContent.append("}");
sendPost(serverURL + "?command=createRequirement&parentFolderId=33", bodyContent.toString());
}
// +-------------------+
// | GET |
// +-------------------+
public void sendGet(String url) throws Exception {
System.err.println("************* [GET] " + url);
URL obj = new URL(url);
con = (HttpURLConnection) obj.openConnection();
addCookie();
con.setRequestMethod("GET");
con.setRequestProperty("User-Agent", USER_AGENT);
//displayDetails(con);
int responseCode = con.getResponseCode();
//System.out.println("\nSending 'GET' request to URL : " + url);
System.out.println("Response Code : " + responseCode);
BufferedReader in = new BufferedReader(new InputStreamReader(con.getInputStream()));
String inputLine;
StringBuffer response = new StringBuffer();
while ((inputLine = in.readLine()) != null) {
response.append(inputLine);
}
System.out.println("response: " + response.toString() + ".");
in.close();
con.disconnect();
}
// +-------------------+
// | POST |
// +-------------------+
private void sendPost(String url, String body) throws Exception {
System.err.println("************* [POST] " + url);
URL obj = new URL(url);
con = (HttpURLConnection) obj.openConnection();
addCookie();
con.setRequestMethod("POST");
con.setRequestProperty("User-Agent", USER_AGENT);
// body
byte[] postData = body.getBytes("UTF8");
int postDataLength = postData.length;
con.addRequestProperty("Content-Type", "application/json");
con.setRequestProperty("Content-Length", ""+postDataLength);
// Send post request
con.setDoOutput(true);
DataOutputStream wr = new DataOutputStream(con.getOutputStream());
wr.write(postData);
wr.flush();
wr.close();
/*
or...
con.addRequestProperty("Content-Type", "application/json");
con.setRequestProperty("Content-Length", Integer.toString(body.length()));
con.getOutputStream().write(body.getBytes("UTF8"));
*/
//displayDetails(con);
int responseCode = con.getResponseCode();
System.out.println("\nSending 'POST' request to URL : " + url);
System.out.println("Response Code : " + responseCode);
BufferedReader in = new BufferedReader(new InputStreamReader(con.getInputStream()));
String inputLine;
StringBuffer response = new StringBuffer();
while ((inputLine = in.readLine()) != null) {
response.append(inputLine);
}
in.close();
System.out.println(response.toString());
con.disconnect();
}
private void addCookie() {
// Cookie: local store --> message
String storedCookie = null;
try {
//System.err.println("local cookie store:" + cookieStore);
if (cookieStore != null) {
List<HttpCookie> cookiesList = cookieStore.getCookies();
//System.err.println("local cookies list:" + cookiesList);
if (cookiesList != null) {
//System.err.println("cookies# in the local store:" + cookiesList.size());
if (cookiesList.size() > 0) {
HttpCookie firstCookie = cookiesList.get(0);
if (firstCookie != null) {
storedCookie = firstCookie.toString();
//System.err.println(">>> set cookie in the message: " + storedCookie);
con.setRequestProperty("Cookie", storedCookie);
} else {
System.err.println("null cookie in local store!");
}
} else {
System.err.println("no cookie available in local store"); // at the first connection, this is normal
}
} else {
System.err.println("null local cookies list!");
}
} else {
System.err.println("null local cookie store!");
}
} catch (Exception e) {
System.err.println("Exception while parsing cookies: " + e);
}
}
public static void main(String[] args) throws Exception {
System.out.println("- - - - - - - - NEW CLIENT - - - - - - -");
CClient client = new CClient();
client.start();
}
}
